Document Type: Original Engineering Research Paper
Series: BOER (Bailipower Original Engineering Research)
Paper Number: BOER-BM-06
Version: 1.0
Bailipower Original Engineering Research
In a three-station busbar machine, in addition to the single automatic control mode in which one input starts a preset cycle and the machine completes the cycle automatically, there is another typical control method: continuous foot-pedal control.
In this control method, the operator participates in the machine motion through continuous foot-pedal input. The control system determines whether the machine should continue moving, stop, or enter the return process according to the operator input, limit status, and predefined control logic.
In the Bailipower BOER-BM control-logic classification system, this type of control is defined as:
B-Class: Continuous Foot-Pedal Control Logic
BOER-BM-05 analyzed the three A-Class configurations—A1, A2, and A3—under single-press automatic control. This article continues the detailed study of specific control configurations and analyzes B1, B2, B3, B4, B5, and B6 within the B-Class.
Although all six configurations use continuous foot-pedal input, they produce different machine behaviors because their limit configurations, forward-motion responses, and return-motion responses are different.
This article focuses on three engineering questions:
Why can continuous foot-pedal input produce different control logics?
Why can B1-B6 still be different even when some configurations use the same single-limit arrangement?
When selecting a three-station busbar machine, how should these differences be understood?
1. What Is B-Class Continuous Foot-Pedal Control Logic?
The core characteristic of B-Class continuous foot-pedal control is:
The operator participates in machine motion through continuous foot-pedal input, while the control system determines the machine response according to the input state, machine feedback state, and predefined control rules.
This is different from A-Class single-press automatic control.
The basic A-Class sequence is:
One input → Automatic execution of a preset cycle → Automatic return → Standby
B-Class control is closer to:
Continuous input → Machine motion → Input or machine state changes → Control system evaluates the conditions again → Continue, stop, or return
Therefore, B-Class control is not simply a matter of having a “foot pedal switch.”
The foot pedal provides the operator input signal.
Limit switches mainly provide machine motion-state feedback.
The actual machine response is determined by the interaction of:
Operator Input + State Feedback + Control Logic + Actuation System
This is the foundation for understanding B1-B6.
2. How Are the Six B1-B6 Control Configurations Classified?
According to the three-station busbar machine control-logic classification framework established in BOER-BM-01, B1-B6 can be understood through three dimensions:
Limit Configuration
Forward Motion Response
Return Motion Response
The six representative configurations are:
| Control Type | Limit Configuration | Forward Motion Response | Return Motion Response |
|---|---|---|---|
| B1 | Upper Limit | Controlled Stop | Automatic Return |
| B2 | Upper Limit | Controlled Return | Automatic Return |
| B3 | Lower Limit | Controlled Stop | Controlled Stop |
| B4 | Lower Limit | Controlled Stop | Automatic Return |
| B5 | Lower Limit | Controlled Return | Controlled Stop |
| B6 | Lower Limit | Controlled Return | Automatic Return |
One point requires particular clarification:
“Controlled Stop” and “Controlled Return” describe the machine's motion-response type. They should not simply be interpreted as a specific foot-pedal action.
The actual operation depends on the control system implemented on the specific machine.
Therefore, this article discusses control-logic types, not one fixed PLC program or one fixed electrical implementation.
3. B1: Upper Limit + Controlled Stop + Automatic Return
B1 uses a single upper limit switch.
The forward motion uses Controlled Stop, while the return motion uses Automatic Return. The upper limit mainly provides the control system with feedback about the return-end state.
3.1 Complete Motion Sequence
Continuous foot-pedal input → Forward motion → Forward motion reaches the stopping condition → Forward motion stops → Automatic return → Upper-limit feedback → Return completed
Here, “Controlled Stop” describes the response type of the forward motion.
The actual stopping condition can be defined by the specific machine control logic and may involve operator input, time parameters, or other control conditions.
Therefore, the classification of B1 is not based on one fixed foot-pedal action. Its defining feature is that forward motion uses a controlled stop while return motion uses automatic return.
3.2 Advantages of B1
3.2.1 Greater operator participation during forward motion
B1 retains a relatively strong degree of operator participation during forward machine motion.
For applications where the operator needs to observe the busbar, tooling, and processing condition and control the forward motion according to the actual situation, this configuration provides operational flexibility.
3.2.2 Automatic return
After the forward motion stops, the machine can execute the return process automatically according to its predefined control logic.
The operator does not need to continuously participate throughout the return process.
3.3 Disadvantages of B1
3.3.1 No direct lower-limit feedback at the processing end
B1 has an upper limit but no lower limit.
Therefore, the control system cannot obtain direct end-position feedback from a lower limit switch at the processing end.
Forward stopping may depend more on operator input, time parameters, or other control conditions. Where processing-position consistency is important, the actual machine setup, operating procedure, and mechanical motion characteristics should also be considered.
3.3.2 Single feedback point at the return end
B1 has only one upper-limit feedback point and no second position feedback point at the return end.
Therefore, the upper limit switch, mechanical triggering mechanism, wiring, and installation condition all need to remain reliable.
3.4 Bailipower Selection and Application Guidance
B1 can be considered for applications where operator participation during forward processing is required while automatic return is preferred.
Key points to examine include:
Forward stopping control + Upper-limit reliability + Automatic return logic
4. B2: Upper Limit + Controlled Return + Automatic Return
B2 also uses a single upper limit switch.
Compared with B1, the main difference is the forward-motion response.
When the forward motion reaches the relevant control condition, the machine does not simply complete the motion cycle by stopping. Instead, it enters the return process.
4.1 Complete Motion Sequence
Continuous foot-pedal input → Forward motion → Forward motion reaches the return condition → Enter return → Automatic return → Upper-limit feedback → Return completed
Here, “Controlled Return” means that the forward motion can transition into return motion according to the relevant control conditions.
The actual transition condition depends on the specific control system and may involve operator input, time conditions, or other machine-state conditions.
4.2 Advantages of B2
4.2.1 Forward motion can directly transition into return
B2 connects the end of the forward-motion process with the return process.
When the relevant control condition is reached, the machine transitions from forward motion into return motion rather than simply remaining at the forward endpoint.
4.2.2 Automatic return
Like B1, B2 uses automatic return.
Once the return process begins, the system completes the return according to its predefined logic, with the upper limit providing feedback at the return end.
4.3 Disadvantages of B2
4.3.1 No direct lower-limit feedback at the processing end
B2 also has no lower limit.
Therefore, the control system cannot directly confirm the processing-end position through a lower-limit switch.
4.3.2 The forward-return condition depends on the actual control logic
“Controlled Return” describes the response type of forward motion.
The specific input or machine state that triggers the return must be understood from the actual control system.
4.4 Bailipower Selection and Application Guidance
B2 can be considered where forward motion needs to transition directly into return after a defined condition is reached, while automatic return is preferred.
Key points to examine include:
Forward-return condition + Upper-limit reliability + Automatic return logic
4.5 Core Difference Between B1 and B2
Both configurations have the same limit and return arrangements:
Upper Limit + Automatic Return
Their difference is the forward-motion response:
B1: Controlled Stop
B2: Controlled Return
This single difference produces a different machine motion process.
5. B3: Lower Limit + Controlled Stop + Controlled Stop
B3 uses a single lower limit switch.
The forward motion uses Controlled Stop, and the return motion also uses Controlled Stop.
Unlike B1 and B2, B3 provides the control system with processing-end position-state feedback through the lower limit.
5.1 Complete Motion Sequence
Continuous foot-pedal input → Forward motion → Lower-limit feedback → Processing-end position reached → Forward motion stops → Return begins → Return motion reaches the stopping condition → Return stops
It is important to clarify:
Lower-limit feedback is not the same thing as processing accuracy.
The lower limit provides processing-end state information. Actual processing dimensions are also affected by mechanical structure, tooling condition, hydraulic dynamics, limit-switch repeatability, machine setup, and other factors.
5.2 Advantages of B3
5.2.1 Position-state feedback at the processing end
When forward motion reaches the lower limit, the control system can receive information about the processing-end state.
Compared with relying entirely on a fixed time value to determine the forward stroke, this approach can reduce dependence on time-only control and may help maintain consistency in the machine motion process.
5.2.2 Operator participation in both forward and return motion
Both forward and return motions use controlled responses.
Therefore, the operator retains a relatively high degree of participation during both motion stages.
5.3 Disadvantages of B3
5.3.1 No upper-limit feedback at the return end
B3 has no upper limit.
Therefore, the control system cannot directly confirm the return-end position through an upper-limit switch.
5.3.2 Single feedback point
The processing end has only the lower-limit feedback point.
Therefore, the lower limit switch, mechanical triggering mechanism, wiring, and installation condition need to remain reliable.
5.4 Bailipower Selection and Application Guidance
B3 can be considered where processing-end position-state feedback is required while the operator is expected to remain actively involved in both forward and return motion.
Key points to examine include:
Lower-limit reliability + Operating procedure + Return control method
6. B4: Lower Limit + Controlled Stop + Automatic Return
B4 uses a single lower limit switch.
The forward motion uses Controlled Stop, while the return motion uses Automatic Return.
6.1 Complete Motion Sequence
Continuous foot-pedal input → Forward motion → Lower-limit feedback → Processing-end position reached → Forward motion stops → Automatic return → Return termination condition reached → Return completed
B4 and B3 share the same:
Lower Limit + Controlled Stop
Their difference is the return response:
B3: Controlled Stop
B4: Automatic Return
6.2 Advantages of B4
6.2.1 Position-state feedback at the processing end
The lower limit provides the control system with processing-end position-state information.
This allows the forward motion to be controlled with reference to actual position feedback rather than relying entirely on a fixed time value.
6.2.2 Automatic return
Compared with B3, B4 changes the return response from controlled stop to automatic return.
This can reduce the operator's continuous involvement during the return stage.
6.3 Disadvantages of B4
No upper-limit feedback at the return end
B4 has no upper limit.
Therefore, the control system cannot directly confirm the return-end position through an upper-limit switch.
If automatic return uses a time parameter or another non-position condition, the return termination process needs to be considered together with the actual control conditions and machine motion characteristics.
6.4 Bailipower Selection and Application Guidance
B4 can be considered where processing-end position-state feedback is required while automatic return is preferred.
Key points to examine include:
Lower-limit reliability + Forward stopping control + Automatic return logic
7. B5: Lower Limit + Controlled Return + Controlled Stop
B5 uses a single lower limit switch.
The forward motion uses Controlled Return, while the return motion uses Controlled Stop.
7.1 Complete Motion Sequence
Continuous foot-pedal input → Forward motion → Forward motion reaches the return condition → Enter return → Return motion reaches the stopping condition → Return stops
Like B3 and B4, B5 uses a lower limit and therefore provides processing-end position-state feedback.
Its key difference lies in the combination of forward-motion and return-motion responses.
7.2 Advantages of B5
7.2.1 Position-state feedback at the processing end
The lower limit provides the control system with processing-end state information.
7.2.2 Forward motion can directly transition into return
Once the relevant control condition is reached, the forward motion can transition into return motion.
7.2.3 Operator participation during return
Because the return motion uses Controlled Stop, the operator remains involved in the return process.
7.3 Disadvantages of B5
7.3.1 No upper-limit feedback at the return end
B5 has no upper limit.
Therefore, the control system cannot directly confirm the return-end position through an upper-limit switch.
7.3.2 Greater operator involvement
Because both forward and return use controlled responses, the operator has a relatively high degree of involvement throughout the motion process. Therefore, consistency in operating procedures should be considered.
7.4 Bailipower Selection and Application Guidance
B5 can be considered where processing-end position-state feedback is required and the operator is expected to participate in the forward-to-return transition and return stopping process.
Key points to examine include:
Lower-limit reliability + Forward-return condition + Return stopping control
7.5 Core Difference Between B5 and B4
Both use:
Lower Limit + Controlled Forward Motion
But their actual combinations are:
B4: Controlled Stop + Automatic Return
B5: Controlled Return + Controlled Stop
Therefore, their machine motion processes are different.
8. B6: Lower Limit + Controlled Return + Automatic Return
B6 uses a single lower limit switch.
The forward motion uses Controlled Return, while the return motion uses Automatic Return.
8.1 Complete Motion Sequence
Continuous foot-pedal input → Forward motion → Lower-limit feedback or forward-return condition reached → Enter return → System automatically executes return → Return termination condition reached → Return completed
B6 and B5 share the same:
Lower Limit + Controlled Return
Their difference is the return response:
B5: Controlled Stop
B6: Automatic Return
8.2 Advantages of B6
8.2.1 Position-state feedback at the processing end
The lower limit provides the control system with processing-end position-state feedback.
8.2.2 Forward motion can transition into automatic return
After the relevant forward-motion control condition is reached, the machine enters the return process.
8.2.3 Automatic return
The return process is executed automatically according to the predefined control logic, reducing the operator's continuous involvement during the return stage.
8.3 Disadvantages of B6
8.3.1 No upper-limit feedback at the return end
B6 has no upper limit.
Therefore, the control system cannot directly confirm the return-end position through an upper-limit switch.
If automatic return uses a time parameter or another non-position condition, the return termination process needs to be considered together with the actual control conditions and machine motion characteristics.
8.3.2 The forward-return condition depends on the actual control system
“Controlled Return” in B6 describes the response type of forward motion.
The specific condition that causes the machine to transition from forward motion to return must be understood from the actual control system.
8.4 Bailipower Selection and Application Guidance
B6 can be considered where processing-end position-state feedback is required and the machine should automatically complete the return after the relevant forward-motion transition condition is reached.
Key points to examine include:
Lower-limit reliability + Forward-return condition + Automatic return logic
9. How Should B1-B6 Be Understood When Selecting a Three-Station Busbar Machine?
When selecting a three-station busbar machine, it is not enough to ask:
“Does this machine use foot-pedal control?”
It is more useful to understand the following questions.
9.1 How does the forward motion stop?
Is the stop controlled by the operator, or does the system automatically respond to a specific machine state or condition?
9.2 What happens when the forward motion ends?
Does the machine stop, or does it directly enter the return process?
9.3 How is the return process controlled?
Does the operator continue to control it, or does the system perform the return automatically?
9.4 What feedback is available at the processing end?
Is a lower limit switch installed?
9.5 What feedback is available at the return end?
Is an upper limit switch installed?
9.6 How is the limit feedback used in the control decision?
Is it used to stop motion, initiate return, or trigger another state transition?
These questions reveal the actual machine control logic more clearly than simply asking whether a machine has a foot pedal.
10. Conclusion
Although B1-B6 all belong to the B-Class Continuous Foot-Pedal Control Logic of three-station busbar machines, they represent six different control configurations because their limit configurations, forward-motion responses, and return-motion responses are different.
B1 and B2 use an upper-limit configuration.
B3, B4, B5, and B6 use a lower-limit configuration.
On this basis, different combinations of:
Controlled Stop
Controlled Return
Automatic Return
produce different machine motion processes.
Therefore, the central engineering conclusion of BM-06 is:
Limit feedback tells the control system what state the machine is in. Control logic determines how the machine responds. Operator input participates in determining the machine motion process.
More specifically:
The same limit configuration can support different control logics, and the same foot-pedal input can produce different machine behaviors.
Therefore, understanding a three-station busbar machine requires more than asking:
Does it have a foot pedal?
Does it have limit switches?
It is more important to understand:
What role does the foot-pedal input play in the control system?
What control decisions use the limit feedback?
How does the forward motion respond?
How does the return motion respond?
These questions provide a practical foundation for understanding the control logic of three-station busbar machines.
Bailipower develops the BOER-BM Original Engineering Research series to explain complex machine-control principles in a clear engineering framework, helping users not only choose the right busbar machine, but also understand and use it effectively.
Scientific. Rational. Feasible. Reliable.
Building machines adapted to industrial working environments, and building machines with industrial cultural quality.
11. Frequently Asked Questions
11.1 What is B-Class Continuous Foot-Pedal Control in a three-station busbar machine?
B-Class Continuous Foot-Pedal Control means that the operator participates in machine motion through continuous foot-pedal input, while the control system determines the machine response according to operator input, machine-state feedback, and predefined control logic.
Unlike A-Class control, in which one input starts a preset automatic cycle, B-Class control retains continuous operator participation in the motion process.
11.2 What are the main differences between B1-B6?
Although B1-B6 all use continuous foot-pedal control, they differ in their limit configurations, forward-motion responses, and return-motion responses.
B1 and B2 use an upper-limit configuration, while B3-B6 use a lower-limit configuration.
The different configurations then combine Controlled Stop, Controlled Return, and Automatic Return in different ways.
11.3 What is the difference between B1 and B2?
Both use an upper limit and automatic return.
Their main difference is the forward-motion response:
B1: Controlled Stop
B2: Controlled Return
Therefore, although their hardware feedback arrangement is the same, their control logic and machine motion processes are different.
11.4 Why do B3, B4, B5, and B6 form four different control configurations even though they all use a lower limit?
Because the lower limit is only one part of the control conditions.
With the same lower-limit configuration, the control system can still use different forward and return responses:
B3: Controlled Stop + Controlled Stop
B4: Controlled Stop + Automatic Return
B5: Controlled Return + Controlled Stop
B6: Controlled Return + Automatic Return
Therefore, the limit configuration alone does not define the complete control logic.
11.5 Does continuous foot-pedal control mean a lower level of automation?
Not necessarily.
The main difference between A-Class and B-Class control is not simply a higher or lower level of automation. It is the way control responsibility is distributed between the operator and the machine.
A-Class control emphasizes automatic execution of a preset cycle after one input.
B-Class control retains continuous operator participation in the motion process.
The appropriate approach depends on the production process and operating requirements.
11.6 Does a lower limit mean that the machine has high processing accuracy?
No.
A lower limit provides position-state feedback at the processing end and can reduce dependence on time-only control. However, actual processing dimensions are also affected by mechanical structure, tooling, hydraulic dynamics, limit-switch repeatability, machine setup, and other factors.
Therefore:
A lower limit is a processing-end position-feedback condition, not processing accuracy itself.
11.7 Does the foot pedal directly determine whether the machine stops or returns?
The foot pedal primarily provides an operator input signal.
Whether the machine continues moving, stops, or returns depends on the control logic, which evaluates the foot-pedal input together with limit feedback and other control conditions.
Therefore:
The operator input signal and the final machine action are not the same thing.
11.8 What should users understand when selecting a B-Class three-station busbar machine?
Instead of simply asking whether the machine uses foot-pedal control, it is useful to understand:
What is the limit configuration?
How does the forward motion respond?
Under what condition does the machine stop or return?
Is the return process operator-controlled or automatic?
What state feedback is available at the processing end and return end?
Only by understanding these points can users identify the actual control logic of the machine and determine whether it is suitable for their production process.
